New Cup & Headband Design

The new 3M PELTOR ComTac VII headset is designed to allow for dual hearing protection. It can be used in combination with 3M PELTOR TEP-300 earplugs, or passive earplugs. A new headband design helps to make transition between rail mounted systems and headband eaiser. It can also help to improve comfort when worn under a ballistic helmet.

Rugged Microphone
The new speech microphone is redesigned and embedded with patented 3M closed cell foam, delivers improved noise cancelling transmission in high noise and wind while also improving dust and water ingress protection ( IP68, 6m / 30 min). The microphone attachment is designed to help accommodate both left handed and right handed
shooters without the need to relocate the microphone to opposite side of the headset.

Environmental Microphones & Natural Interaction Behavior (NIB)
New design and wind screen attachment help to improve environmental listening. Choose between classic mode, or advanced mode with 5 different Mission Audio Profiles (MAP); Silent, Observation, Patrol, Conversation or Comfort. Natual Interaction Behavoiur (NIB), helps to improve close range face-to-face communication in steady
state noise environments.

NIB offers electronic, headset-to-headset communication with a transmission range of ≈10 m/11 yd from the speaker. There is no limit regarding how many people within that transmission range that can receive the transmission. Up to 4 users within ≈150 m/165 yd can transmit simultaneously using 1 of 4 open slots/channels. Once all 4 channels are active, no one else in the group can transmit until a channel becomes available. If a fifth person tries to transmit, a beeping sound will indicate that the message was not transmitted. This ≈150 m/165 yd range is in an open field (line in sight) and may be reduced by physical structures.

Mission Audio Profiles (MAP)

The 3M PELTOR ComTac VII offers a new way to adjust the auditory settings of your headset for your mission. Traditionally, a headset has a set frequency response, and the operator can only increase or decrease the volume. The MAP function provides advanced environmental listening modes that allow access to a variety of gain settings, but with frequency shaping, to enhance auditory performance in five conditions. The MAP Profiles have been designed with a variety of combat and combat support operations in mind.

Advanced level dependent function for environmental listening

Mission Audio Profile 1: Observation Highest volume and widest frequency response to maximize hearing when the user is still (overwatch, hide spot, stop to listen, etc).
Mission Audio Profile 2: Patrol High volume with reduced high frequencies to limit sounds such as footsteps on gravel, grass moving under feet,equipment moving on body.
Mission Audio Profile 3: Conversation Maximizes the frequencies important for face-to-face communications while lowering the frequencies outside of the average speech band.
Mission Audio Profile 4: Comfort Low volume and narrow frequency response to be used when in noise for long periods of time (tactical vehicle, air transport) where environmental listening is not prioritized over communications and overall comfort.
Mission Audio Profile 5: Silent Silent mode for communicating in high levels of noise when situational awareness is difficult to achieve

Key Features

New headband design
Dual hearing protection
IP68 noise cancelling microphone
Level dependent function for environmental listening
New microphone attachment. Accomodates both left handed and right handed shooters without the need to relocate the microphone to opposite side of the headset.
Near Field Magnetic Induction (NFMI)
Natural Interaction Behaviour (NIB)

Technical Specifications

Speech Microphone Type: Dynamic (MT71) waterproof (IP68), 6m / 30min
Battery Type: 2 x AAA
Environmental listening: Approximately 50 hours
Environmental & NIB: Approximately 30 hours
Natural Interaction Behavior (NIB) Freaquency band: 864 Mhz and 915 Mhz
Natural Interaction Behavior (NIB) Operation mode: Full Duplex
Natural Interaction Behavior (NIB) Range: Approximately: Approximately 3-5m (Optimal for communication), Approximately 5-10m: Fade in and fade out
Natural Interaction Behavior (NIB) Modulation: TDMA protocol
Near Field Magnetic Induction (NFMI) Transmission rate: 596 kbit/s
Near Field Magnetic Induction (NFMI) Range: Approximately 50 cm
Near Field Magnetic Induction (NFMI) Frequency: 9.8 – 11.7Mhz
Weight with batteries: 326 g (standard foam ring), 361 g (with gel ring)
Operating temp: -20 to +55°C
Shelf Life: Headset: 5 years, excluding batteries
Waterproof Rating: Salt water (5%) 2m at 30 min
Recommended Storage Conditions: 5 years Indoor Controlled Climate (<90% humidity)
Environmental Performance: Tested in accordance with MIL- STD-810G
